Scantech-ID Discovery SG-20 59
6.3.4 Set the Back-Office/Server IP address in the SG-20
terminal
Note: at the Discovery with hardware P/N from A360104, the IP address can
also be configured by using the buttons of the Discovery. See section 6.4 for
details.
1 Remote IP Address : (192) Input the required Back-Office/Server IP Address,
format: a xxx xxx xxx xxx a
2 Remote Port (01024) ? a a
3 DisConnMode (00) ? a a
4 FlushMode (00) ?
a a
5 DisConnTime ( 00:00) ?: a a
6 SendChar 1 (00) ? a a
7 SendChar 2 (00) ? a a
8 Select a 9 a = Save and Exit
6.4 CONFIGURING THE DISCOVERY USING THE BUTTONS
At the Discovery with hardware P/N from A360104 and higher the most
frequently used parameters (e.g. IP addresses, gateway address and subnet
mask) can also be configured by using the buttons on the Discovery terminal
itself. So without a remote utility or a Telnet session etc, but simply by applying
the Service Screens. This mode can be entered by
1. Pressing button #4 for 5 seconds and
2. Entering the authorisation code by pressing buttons 1, 2, 3, and 4
(=default sequence)
Button 1
Button 2
Button 3
Button 4
