Ethernet Configuration 58
6.3.3 Checking the internal Discovery communication
settings
Select a 1 a in order to check the communication settings between the
Discovery unit itself and the Ethernet module. NOTE: The Discovery/Ethernet is
supplied from the factory with the following settings:
•
At Discoveries with hardware P/N A360103: Jumpers in RS-232 mode,
data-comm settings: 9600 Baud, 8 data, 1 stop bit, echo off, RTS/CTS
off. CR (! SG-20 Default).
•
Since Discoveries with hardware P/N A360104 or higher, the data-comm
speed is increased with a factor 4 to: 38.400 baud, 8 data, No parity, 1,
Echo Off, RTS/CTS On.
The communication settings of the Discovery unit itself can be checked
(and corrected if necessary) by entering the Service Menu, using the 4
buttons. See Chapter 5 for details.
3.1 Baudrate (9600) 38400 a a a a keep (9600) at
Discovery with P/N
A360103
3.2 I/F Mode (4C) ?
a a
3.3 Flow (00) ? 02
a a a a keep (00) at
Discovery with P/N
A360103
3.4 Port No (01024) ?
a a
3.5 Connect Mode
(00)
C5 5 a = Autoconnect mode (= client
mode), i.e. after power-up the unit looks
automatically for contact
