Scantech-ID Discovery SG-20 119
K TECHNICAL SPECIFICATIONS
Discovery SG-20
Electrical
Power supply
voltage
90-264 V ac 50/60 Hz
Power
consumption
10 Watt max
Interfaces RS232, RS422, RS485 and optional Ethernet or WiFi.
Scanner characteristics
Light source Visible laser diode (630 – 670 nm)
Depth of field 250 mm (= maximum reading distance)
Scan pattern Omnidirectional
Bar code types EAN/UPC/JAN + Add-on, code 32 (Ital. Pharmacode)
Code 128, EAN 128, Code 39 (+ full ASCII), Code 93,
Codabar, Interleaved 2/5
Physical
Dimensions 298 (h) x 181 (w) x 100 (d) mm
Display Back Lit STN graphical 240x128 pixels
Housing Cycolac
Window Anti-reflex coated
Environmental
Operating
temperature
0°C … 40°C
Humidity 20% .. 95% RH (non condensing)
Safety
Laser Safety IEC 825-1 (1993) Class I, U.S. 21CFR1040 Class IIa
