Ethernet Configuration 54
Phase Section
1. Make connection between your host or Back-Office
computer and the SG-20/Ethernet terminal, using Discovery
TCPIP Terminal.exe.
6.3.1
2.
Set the address of the individual terminal (at least, if
required) *1
6.3.2
3. Checking the internal Discovery communication settings *1
6.3.3
4. Set the Back-Office/Server IP address in the individual SG-
20 terminal *1
6.3.4
*1 : At the Discovery with hardware P/N from A360104, these parameters can
also be configured by using the buttons. See Chapter 6.4 Configuring the
Discovery using the buttonsfor more details.
In the examples below, IP address 192.137.81.210 is used for the Discovery
terminal and the MAC address of the specific unit is: 00-20-4A-52-4B-19.
6.3.1
Making Connection
Start-up U-Start, the demo and configuration program, which you received on
the Discovery CD-ROM enclosed with the Discovery or by E-mail (Ustart.exe for
Windows).
