120 Appendices
Separator Box/ Network Box - Classic version
Electrical
Power supply 4,65 – 5.5 Vdc
Power consumption 2 Watt
Interfaces RS-232: optical separation up to 1600V
RS-422: optical separation up to 1600V
RS-485: optical separation up to 1600V
Physical
Dimensions 30x86x125 mm (hxwxd)
Housing Coated steel
Environmental
Operating temperature 0°C … 40°C
Humidity 20% .. 95% RH (non condensing)
Separator Box/ Network Box – Version 2
(version 2 is fully backward compatible with the classic version)
Electrical
Power supply 5 Vdc
±
5% (double powerplug option)
Power consumption 1 Watt
Interfaces RS-232: optical separation up to 1600V
(double connector option).
RS-422: optical separation up to 1600V.
RS-485: optical separation up to 1600V.
Physical
Dimensions 25x136x app. 89 mm (hxwxd)
Housing Anodized aluminum
Environmental
Operating temperature 0°C … 40°C
Humidity 20% .. 95% RH (non condensing)
