94 Appendices
S7 Record
The type of record field is 'S7'. The address field contains the starting execution
address and is interpreted as 4-byte address. There is no data field.
S8 Record
The type of record field is 'S8'. The address field contains the starting execution
address and is interpreted as 3-byte address. There is no data field.
S9 Record The type of record field is 'S9'. The address field contains the
starting execution address and is interpreted as 2-byte address. There is no data
field.
S7, S8 and S9 records are interpreted by the Discovery as 'End of File' and serve
no other purpose.
Note 1 The Discovery uses the Motorola S-Rec format.
Note 2 When sending a S-Record to the Discovery, it should be followed by
a CR.
Example of an S-rec file :
This is an example of an S-rec file, describing the pixels of icon #1, which looks
like this :
The File :
S0030000FC
S2240600003F3F3F3C20000004200000072000000720000007200000072000000720000007CE
S22406002020000007200000072000000720000007200000072000000720000007200000077D
S22406004020000007200000072000000720000007200000072000000720000007200000075D
S22406006020000007200000072000000720000007200000073F3F3F3F0F3F3F3F0F3F3F3F1E
S804000000FB
Explanation of the 2nd line of the file :
S2240600003F3F3F3C20000004200000072000000720000007200000072000000720000007CE
This is an S2 record, which contains an address followed by the data to be written.
S2240600003F3F3F3C20000004200000072000000720000007200000072000000720000007CE
Hex value 24 = 36 decimal.
36 byte-pairs follow after this (3 address, 32 data, 1 checksum)
S2240600003F3F3F3C20000004200000072000000720000007200000072000000720000007CE
The address at which the first databyte of this line will be programmed in this
case 0x060000, the location of the icon #1.
