3: Software Operation

RAYSPHERE-1700-02-201304

The four functions appear in the upper command line of the main screen. Pressing one of the controls
changes the background of the function name to green. The section becomes active and the page with the
function details appears.

System Tab

The system tab allows you to load and save data.

Load All

Load All (

) loads the following file types with the name you specify:

• Classification_Date_time_Name.txt
• Configuration_Date_Time_Name.cfg
• PDcurr_Date_Time_Name.cfg
• Report_Date_Time_Name.pdf
• Spec_merge_Date_Time_Name.txt
• Spec_NR_Date_Time_Name.txt
• Spec_QE_Date_Time_Name.txt
• Spectrum4000-1100_Date_Time_Name.txt

See

File Types and Data Files

for more information.

Load Config

Load Config (

) loads a configuration file to operate RaySphere under conditions defined in the file.

Save All

Save All (

) saves all data as one of the following file types:

• Classification_Date_time_Name.txt
