6.4.2 Command Reference Table
Modems expect numerical values in hexadecimal. Hexadecimal values are designated by
a “0x” prefix. Decimal equivalents are designated by a “d” suffix.
AT
Command
Binary Command AT Command Name Parameter Range
Command
Category # Bytes
Returned
Default
%V 0x3B (59d) Board Voltage
0x2CCCA - 0x5BFFA [read-
only]
Diagnostics 4 -
AM 0x40 (64d) Auto-set MY -
Networking &
Security
- -
AP
v2.x20*
- API Enable 0 - 2
Serial
Interfacing
1 0
AT 0x05 (5d) Guard Time After 2 - (ATST-3) [x 100 msec]
Command
Mode Options 2
0x0A (10d)
BD 0x15 (21d) Interface Data Rate
0 - 8 (standard rates)
0x39 - 0x1C9C38 (non-
standard rates)
Serial
Interfacing
4 3
BR 0x39 (57d) RF Data Rate 0 - 1 RF Interfacing 1 1
BT 0x04 (4d) Guard Time Before 0 - 0xFFFF [x 100 msec]
Command
Mode Options 2
0x0A (10d)
CC 0x13 (19d)
Command Sequence
Character
0x20 - 0x7F
Command
Mode Options 1 0x2B ["+"]
(43d)
CD 0x28 (40d) GPO2 Configuration 0 - 4
Serial
Interfacing
1 2
CF - Number Base 0 - 2
Command
Mode Options 1
1
CN 0x09 (9d) Exit Command Mode -
Command
Mode Options -
-
CS 0x1F (31d) GPO1 Configuration 0 - 4
Serial
Interfacing
1 0
CT 0x06 (6d)
Command Mode
Timeout
2 - 0xFFFF [x 100 ms]
Command
Mode Options 2
0xC8 (200d)
DB 0x36 (54d)
Received Signal
Strength
0x6E - 0x28 [read-only] Diagnostics 2 -
DT 0x00 (0d) Destination Address 0 - 0xFFFF
Networking &
Security
2 0
E0 0x0A (10d) Echo Off -
Command
Mode Options -
-
E1 0x0B (11d) Echo On -
Command
Mode Options -
-
ER 0x0F (15d) Receive Error Count 0 - 0xFFFF Diagnostics 2 0
FH 0x0D (13d)
Force Wake-up
Initializer
-
Sleep (Low
Power)
- -
FL 0x07 (7d) Software Flow Control 0 - 1
Serial
Interfacing
1 0
FS 0x3E (62d) Forced Sync Time 0 - 0xFFFF [x 10 msec] RF Interfacing 2 0
