5.3.2 Radio Modem Configuration Screen
The Radio Modem Configuration Screen is used to configure your radio modem
The first screen contains options that configure your PC COM port to communicate with
the radio modem.
Use the pull down menu items to select the following options.
Model: This allows you to specify the model number you are trying to connect to.
Figure 5-11 Model Number Selection Pull Down Menu
COM Port: This allows you to specify the COM Port your PC is configured to use to
connect to the radio modem. COM1 through COM16 may be specified.
Figure 5-12 COM Port Pull Down Menu
