Document Number: pnZXTxRM-0712m
Page
151
RS-422
Connector Terminal Block
Lines TDA (-), TDB(+), RDA (-), RDB (+), GND
Termination 120 Ohm selectable (in or out)
RS-485 (2/4 Wire)
Connector Terminal Block
Lines TDA (-), TDB(+), RDA (-), RDB (+), GND
Data A (-), Data B (+), GND
SD control Automatic Bit Wise
Termination 120 Ohm Dipswitch selectable
Link Fault Output No wireless signal or RSSI LED‟s off
Connector Terminal Block
Output type Open drain 50mA (PNP – Sourcing)
Power Supply
Connector Terminal Block
Input Voltage 10 –30VDC
Power Consumption
ZXT9-RM
1.7 Watts Typical
5.8 Watts Maximum
Power Consumption
ZXT 24 -RM
1.2 Watts Typical
3.5 Watts Maximum
Dimensions 5.12 x 5.12 x 2.37 in (130.1 x 130.1 x 60.2 mm)
Environmental Intended for indoor and outdoor use
Operating
Temperature
-40 to 74ºC (-40 to 165ºF)
Storage Temperature -40 to 85ºC (-40 to 185ºF)
Operating Humidity 0 to 95% non-condensing
Enclosure Rating
Rating IP67
Mounting Wall mounting
Agency Approvals
CE EN55022: 2006 Class A Emissions
EN61000-6-2 Generic Standards for Industrial Environments
EN61000-4-2: 2008 Electro-Static Discharge (ESD)
EN61000-4-3: 2006 Radiated Field Immunity (RFI)
EN61000-4-4: 2004 Electrical Fast Transients-Burst (EFT)
EN61000-4-5: Ed2, 2005 Electrical Surges
EN61000-4-6: 2005 Conducted Immunity
FCC Class A
FCC ID – ZXT9-RM – OUR-9XTEND
FCC ID – ZXT24-RM – OUR-XBEEPRO
