Appendix B
– Default Configuration Settings
B. Appendix B
– Default Configurations
B.1 Restore Default Configurations
Push Button 1 – Located behind the cover in the upper right corner.
Used to restore default configuration.
Refer to section 2.5.6 and figure 2-4.
B.2 ZKT9-RM Default Configuration
Basic Modem Settings
Channel Number
– 00
Network Identifier – 3332
Destination Address – 0000
Baud Rate – 9600
Parity None
Stop Bit
– 1 Stop Bit
Flow Control – No Software Flow Control
Advanced Modem Settings
Networking & Security
ID
– Modem VID – 3332
HP – Hopping Channel – 0
DT – Destination Address – 0
MY – Source Address – FFFF
MK – Address Mask – FFFF
RR – Retries – A
MT – Multiple Transmit – 0
RN – Delay Slots – 0
TT – Streaming Limit – 0
KY – AES Encryption Key – 0
Serial Interfacing
BD
– Baud Rate – 3
NB – Parity – 3
SB – Stop Bits – 0
RB – Packetization Threshold – 2048
PK – Maximum RF Packet Size – 3
CS – Pin 9 Configuration – 0
RT – Pin 9 Configuration – 0
CD – Pin 3 Configuration – 3
FL – Software Flow Control – 0
FT – Flow Control Threshold – BEF
RF Interfacing
BR
– RF Data Rate – 1
PL – TX Power Level – 4
TX – Transmit Only – 0
FS – Forced Sync Time – 0
Diagnostics
RP
– RSSI Timer – 20
