LED Status

Note: In order for the RSSI LED to continuously indicate the signal
strength, set the RP command (RSSI PWM Timer) to FF.

Front Panel LED

Status

RSSI (Signal Strength)

8 Green LED‟s indicate signal
from weak to strong

Power

Green LED

Receive Data

Green LED

– blinks when

SERIAL data is received

Transmit Data

Green LED

– blinks when

SERIAL data is transmitted.
