Appendix A
– Specifications
A. Appendix A
– Specifications
RF Properties
Physical Standard IEEE 802.15.4
Frequency ZXT9-RM 900MHz ISM Band (902 – 928 MHz)
ZXT24-RM – 2.4 GHz ISM Band (2.4 – 2.5 GHz)
Transmit Power
ZXT9-RM
1 mW
10 mW
100 mW
500 mW
1 W
Software Selectable
Transmit Power
ZXT24-RM
10 mW
16 mW
25 mW
30 mW
63 mW
Software Selectable
Receiver Sensitivity
ZXT9-RM
-100 dBm
Receiver Sensitivity
ZXT24-RM
-100 dBm
Over the Air Data
Rate
ZXT9-RM – 9.6 kbps or 115.2 kbps (software selectable)
ZXT24-RM – 250 kbps (fixed)
Range (ZXT9-RM)
Outdoor
Supplied Antenna – 14 Miles (23 Kilometers)
High Gain Antenna – 40 Miles (64 Kilometers)
Range (ZXT24-RM)
Outdoor
Supplied Antenna – 1.5 Miles (2.4 Kilometers)
High Gain Antenna – 10 Miles (16 Kilometers)
Range estimates based on optimal RF conditions and an
unobstructed line of sight.
Transmission Method
ZXT9-RM - Frequency Hopping Spread Spectrum (FHSS)
ZXT24-RM - Direct Sequence Spread Spectrum (DSSS)
Modulation FSK (Frequency Shift Keying)
Channel Capacity
ZXT9-RM - 10 hop sequences share 50 frequencies
ZXT24-RM 12 Direct Sequence Channels
Network Topologies Peer-to-Peer, Point-to-Point, Point-to-Multipoint
Encryption 256 bit AES (ZXT9-RM)
Software Zlinx Manager
Support Windows XP (32 and 64 bit), Windows 7 (32 and 64 bit), and Vista
(32 and 64 bit).
Antenna Options RPSMA Connector
Radio Address Software Selectable
Serial settings
Baud ZXT9-RM 1.2 kbps to 230.4 kbps
Baud ZXT24-RM 1.2 kbps to 115.2 kbps
Data bit 8
Parity None
Stop bit 1
RS-232
Connector Terminal block
Lines TD, RD, RTS, CTS, GND
