93
11050A–PMAAC–07-Apr-10
AT73C246
Name: PMU_MASK
Access: Read / Write
Address: 0x0C
Name: PMU_IT
Access: Read Only
Address: 0x0D
7 6 5 4 3 2 1 0
- - - - - -
RTC_ALA
RM
RTC_IT
Table 13-21. PMU_MASK (0x0C) Structure
Bit Name Description Reset value
7:2 - unused 111111
1 RTC_ALARM
Mask RTC alarm
0: not masked
1: masked
1
0 RTC_IT
Mask RTC interrupt
0: not masked
1: masked
1
7 6 5 4 3 2 1 0
- - - - - -
RTC_ALA
RM
RTC_IT
Table 13-22. PMU_IT (0x0D) Structure
Bit Name Description Reset value
7:2 - unused 000000
1 RTC_ALARM
RTC alarm interrupt
0: default value
1: RTC alarm has occurred. Reset to 0 at read.
0
0 RTC_IT
RTC interrupt
0: default value
1: RTC interrupt has occurred. Reset to 0 at read.
0
