6. Absolute Maximum Ratings
Notes: 1. Refer to Power Dissipation Rating section
2. According to specifications MIL-883-Method 3015.7 (HBM - Human Body Model) / JESD22 A115 (MM - Machine Model)
7. Recommended Operating Conditions
Note: 1. Refer to Power Dissipation Rating section
8. Power Dissipation Ratings
Note: 1. According to specification JESD51-5
Table 6-1. Absolute Maximum Ratings
Operating Temperature (Industrial).................-40 C to + 85 ⋅C (1) *NOTICE: Stresses beyond those listed under “Absolute Maximum
Ratings” may cause permanent damage to the device.
This is a stress rating only and functional operation of
the device at these or other conditions beyond those
indicated in the operational sections of this specification
is not implied. Exposure to absolute maximum rating
conditions for extended periods may affect device reli-
ability.
Storage Temperature......................................-55°C to + 150°C
Power Supply Input on V
INSYS
, V
IN{0,1,3,4},
V
PAD
.. -0.3V to + 5.5V
Power Supply Input on V
IN2
, A
VDD
...................... -0.3V to + 3.6V
Digital I/O Input Voltage...................................... -0.3V to + 5.5V
All Other Pins.......................................................-0.3V to + 5.5V
ESD (all pins).........................................2 KV HBM / 100V MM (2)
Table 7-1. Recommended Operating Conditions
Parameter Condition Min Max Units
Operating Ambiant Temperature (1) -40 85 °C
Power Supply Input V
INSYS
2.5 5.5 V
Power Supply Input V
IN{0,1,3,4}
2.9 5.5 V
Power Supply Input V
IN2
1.65 3.6 V
Power Supply Input A
VDD
2.7 3.6 V
Power Supply Input V
PAD
1.75 5.5 V
Table 8-1. Recommended Operating Conditions
Parameter Condition Min Typ Max Units
Junction Temperature (Tj) -40 125 °C
R
THjA
(1)
Package thermal junction to ambient
resistance
30 35 °C / W
Maximum On-chip Power Dissipation
Ambient temperature = 70°C 1.8 1.6 W
Ambient temperature = 85°C 1.3 1.1 W
