De-Emphasis Filter Frequency Response
12.7.3.1
De-Emphasis Filter: Frequency Response & Error (FS = 32kHz)
Figure 12-21. De-Emphasis Filter: Frequency Response & Error (FS = 32kHz)
12.7.3.2
De-Emphasis Filter: Frequency Response & Error (FS = 44.1kHz)
Figure 12-22. De-Emphasis Filter: Frequency Response & Error (FS = 44.1kHz)
12.7.3.3
De-Emphasis Filter: Frequency Response & Error (FS = 48kHz)
Figure 12-23. De-Emphasis Filter: Frequency Response & Error (FS = 48kHz)
Response (dB)
Fequency (Hz)
Response (dB)
Fequency (Hz)
Error
Response
Response (dB)
Fequency (Hz)
Response (dB)
Fequency (Hz)
Error
Response
Response (dB)
Fequency (Hz)
Response (dB)
Fequency (Hz)
Error
Response
