117
11050A–PMAAC–07-Apr-10
AT73C246
Name: ADC_MUX_2
Access: Read / Write
Address: 0x32
7 6 5 4 3 2 1 0
- - - - ANA3 ANA2 ANA1 ANA0
Table 13-62. ADC_MUX2 (0x32) Structure
Bit Name Description Reset value
7:4 unused - 0000
3 ANA3
ANA3 channel selection
0: Not selected
1: Selected
1
2 ANA2
ANA2 channel selection
0: Not selected
1: Selected
1
1 ANA1
ANA1 channel selection
0: Not selected
1: Selected
1
0 ANA0
ANA0 channel selection
0: Not selected
1: Selected
1
