Name: ADC_CTRL
Access: Read / Write
Address: 0x30
7 6 5 4 3 2 1 0
ON_ADC ON_BUF - - - TS
Table 13-59. ADC_CTRL (0x30) Structure
Bit Name Description Reset value
7 ON_ADC
ADC function
0: OFF
1: ON
0
6 ON_BUF
Analog buffer
0: OFF
1: ON
0
5:3 unused - 000
2:0 TS Sampling period 000
Table 13-60. ADC Sampling Period Selection Table
TS
SAMPLING
PERIOD (s)
000 0.01
001 0.02
010 0.1
011 1
100 2
101 3
110 4
111 Max speed
