148
11050A–PMAAC–07-Apr-10
AT73C246
15.5 AUDIO
Unless otherwise noted, the reported measurement were performed at room temperature with AVDD = 3.3V supplied from
LDO4. Typical components as described in
Section 5. “Application Block Diagram” on page 8 are used.
Figure 15-13. Microphone Recording Waveforms
Differential Microphone Recording ( Path 5)
-1dBV / 1kHz Input - Fs = 48kHz - 16kpts FFT
Differential Microphone Recording ( Path 5)
-60dBV / 1kHz Input - Fs = 48kHz - 16kpts FFT
Differential Microphone Recording ( Path 5)
THD+N Ratio Versus Input Level
