Name: HPLVOL
Access: Read / Write
Address: 0x1A
7 6 5 4 3 2 1 0
HPLVOL
Table 13-45. HPLVOL (0x1A) Structure
Bit Name Description Reset value
7:0 HPLVOL Headphone Left volume selection 00000000
Table 13-46. Headphone Left Volume Selection Table
HPLVOL
GAIN
(dB)
HPLVOL
GAIN
(dB)
HPLVOL
GAIN
(dB)
HPLVOL
GAIN
(dB)
≤10110010
MUT
E
11001000 -56 11011110 -34 11110100 -12
10110011 -77 11001001 -55 11011111 -33 11110101 -11
10110100 -76 11001010 -54 11100000 -32 11110110 -10
10110101 -75 11001011 -53 11100001 -31 11110111 -9
10110110 -74 11001100 -52 11100010 -30 11111000 -8
10110111 -73 11001101 -51 11100011 -29 11111001 -7
10111000 -72 11001110 -50 11100100 -28 11111010 -6
10111001 -71 11001111 -49 11100101 -27 11111011 -5
10111010 -70 11010000 -48 11100110 -26 11111100 -4
10111011 -69 11010001 -47 11100111 -25 11111101 -3
10111100 -68 11010010 -46 11101000 -24 11111110 -2
10111101 -67 11010011 -45 11101001 -23 11111111 -1
10111110 -66 11010100 -44 11101010 -22 00000000 0
10111111 -65 11010101 -43 11101011 -21 00000001 1
11000000 -64 11010110 -42 11101100 -20 00000010 2
11000001 -63 11010111 -41 11101101 -19 00000011 3
11000010 -62 11011000 -40 11101110 -18 00000100 4
11000011 -61 11011001 -39 11101111 -17 00000101 5
11000100 -60 11011010 -38 11110000 -16 >=00000110 6
11000101 -59 11011011 -37 11110001 -15
11000110 -58 11011100 -36 11110010 -14
11000111 -57 11011101 -35 11110011 -13
