83
11050A–PMAAC–07-Apr-10
AT73C246
Name: PMU_WAKEUP_TRIG
Access: Read Only
Address: 0x02
Note: Please refer to Section 11. “PMU Functional Description” on page 25
7 6 5 4 3 2 1 0
- - RTCR PWREN WAKEUP3 WAKEUP2 WAKEUP1 WAKEUP0
Table 13-4. PMU_WAKEUP_TRIG (0x02) Structure
Bit Name Description Reset value
7:6 - unused 00
5 RTCR WAKEUP_EVENT trigged on RTC alarm 0
4 PWREN WAKEUP_EVENT trigged on PWREN 0
3 WAKEUP3 WAKEUP_EVENT trigged on WAKEUP3 0
2 WAKEUP2 WAKEUP_EVENT trigged on WAKEUP2 0
1 WAKEUP1 WAKEUP_EVENT trigged on WAKEUP1 0
0 WAKEUP0 WAKEUP_EVENT trigged on WAKEUP0 0
