AT73C246
Name: MICRVOL
Access: Read / Write
Address: 0x17
7 6 5 4 3 2 1 0
- - MICRVOL
Table 13-39. MICRVOL (0x17) Structure
Bit Name Description Reset value
7:6 - unused 0
5:0 MICRVOL Microphone Right volume selection 000000
Table 13-40. Microphone Right Volume Selection Table
MICRVOL GAIN(dB) MICRVOL GAIN(dB) MICRVOL GAIN(dB)
000000 0 010000 16 100000 32
000001 1 010001 17 100001 33
000010 2 010010 18 100010 34
000011 3 010011 19 100011 35
000100 4 010100 20 100100 36
000101 5 010101 21 100101 37
000110 6 010110 22 100110 38
000111 7 010111 23 100111 39
001000 8 011000 24 101000 40
001001 9 011001 25 101001 41
001010 10 011010 26 101010 42
001011 11 011011 27 101011 43
001100 12 011100 28 101100 44
001101 13 011101 29 101101 45
001110 14 011110 30 101110 46
001111 15 011111 31 Other values 46
