Memory
Programming
Program and Data
Memory Lock Bits The ATtiny26 provides two Lock bits which can be left unprogrammed (“1”) or can be
programmed (“0”) to obtain the additional features listed in Table 48. The Lock bits can
only be erased to “1” with the Chip Erase command.
Note: 1. “1” means unprogrammed, “0” means programmed
Notes: 1. Program the Fuse bits before programming the Lock bits.
2. “1” means unprogrammed, “0” means programmed
Table 47. Lock Bit Byte (1)
Lock Bit Byte Bit No Description Default Value
7 – 1 (unprogrammed)
6 – 1 (unprogrammed)
5 – 1 (unprogrammed)
4 – 1 (unprogrammed)
3 – 1 (unprogrammed)
2 – 1 (unprogrammed)
LB2 1 Lock bit 1 (unprogrammed)
LB1 0 Lock bit 1 (unprogrammed)
Table 48. Lock Bit Protection Modes
Memory Lock Bits
Protection Type LB Mode LB2 (2) LB1 (2)
1 1 1 No memory lock features enabled.
2 1 0
Further programming of the Flash and EEPROM is
disabled in parallel and serial programming mode. The
Fuse bits are locked in both serial and parallel
programming mode.
(1)
3 0 0
Further programming and verification of the Flash and
EEPROM is disabled in parallel and serial programming
mode. The Fuse bits are locked in both serial and parallel
programming mode.
(1)
