Chapter 2 Operation
86
Use this formula to determine printer speed in relation to bar code
height:
NOTE: Set Min. Code Height to the height of the shortest bar code
on the label.
By changing the Min. Code Height, the printer and slew speeds will
be changed automatically.
To change the Min. Code Height:
1. Press to take the printer offline and place the printer in
Menu mode.
2. If necessary, press
↓ and ↵
at the same time to unlock the
↵
key.
3. Press until VALIDATOR displays.
4. Press
↓ until Min. Code Height displays.
5. Press + or – to scroll through the choices: 0.13 to 1.00 inches in
0.01 inch increments. The default is 0.30 inches.
6. Press
↵
to select the desired value. The printing and slew
speeds will be changed after
↵
is pressed.
7. Press
↓ and ↵
at the same time to lock the
↵
key, then press
PAUSE to take the printer offline.
8. Press PAUSE again to put the printer online.
To set the printer speed manually:
1. Press to take the printer offline and place the printer in
Menu mode.
2. If necessary, press
↓ and ↵
at the same time to unlock the
↵
key.
3. Press until MEDIA CONTROL displays.
4. Press
↓ until Print Speed displays.
5. Press + or – to scroll through the choices.
6. Press
↵
to select the desired value.
7. Press
↓ and ↵
at the same time to lock the
↵
key, then press
PAUSE to take the printer offline.
8. Press PAUSE again to put the printer online.
Bar Code Height In Inches
0.030
Maximum Printer Speed In
Inches Per Second
=
..
.
..
.
..
.
..
.
