Restore the printer to operation – Printronix Online Data Validator User Manual
Page 33
Attach the Power/Data Cable
33
8.
Gently pull the power/data cable to minimize the slack along
and behind the bracket. Push any excess slack through the
grommet.
9.
Once the power/data cable is properly positioned, pull the tie
wraps snug against the cable and bracket and cut off the
excess.
Restore the Printer to Operation
1.
Lower the media cover.
2.
Engage the tabs on the bottom of the frame side cover in the
slots in the printer frame.
3.
Rotate the cover into position.
4.
Tighten the two captive screws. (Figure 2.)
5.
Plug the AC power cord into the printer and the power source.
6.
Set the printer power switch to | (On).
