Chapter 2 Configuring the Validator
66
1. Press to take the printer offline and place the printer in
Menu mode.
2. If necessary, press
↓ and ↵
at the same time to unlock the
↵
key.
3. Press until VALIDATOR displays.
4. Press
↑ until Defects displays.
5. Press + or – to scroll through the percentage values: 0% to
100%. The default is 21%.
6. Press
↵
to select the desired value.
7. Press
↓ and ↵
at the same time to lock the
↵
key, then press
PAUSE to take the printer offline.
8. Press PAUSE again to put the printer online.
Overall Grade
This menu item sets the value used by the validator for pass/fail
threshold during the analysis of bar codes. Instead of a letter grade,
numbers are used to allow for more resolution. The numbers can
be translated to letter grades according to the 4.0 grade table
below.
Any bar code with a grade below this threshold value will cause the
printer to display the Overall Grade Fail error message (see “Error
Messages” on page 96) and take the appropriate error action.
Higher values create a stricter pass criterion.
Table 4. Grading Scale for Overall Grade
Letter Grade Grade Numerical Range
A 3.5 to 4.0
B 2.5 to 3.4
C 1.5 to 2.4
D 0.5 to 1.4
F 0.0 to 0.4
..
.
..
.
