This operation can be done from the Channel Explorer and from the Control Panel. A
switch from an application automatically applies to the other one.
Prerequisites
• The appropriate configuration must have been done from the Remote Installer
regarding the communication parameters and the association of router IN ports
physically linked to player channels.
• The Router Control service is started.
• A player channel physically connected to a router IN port has been assigned to the
Control Panel.
How to Assign a Router OUT Port to a Player Channel
To assign an OUT port of a video router to a player channel from the Control Panel or to
change the assignment, proceed as follows:
1. Click the Change Player Output button next to the Player field.
The Assign Player Destination window opens:
It lists all the router OUT ports already associated to the player channel.
2. To remove an association between a video router OUT port and the player channel,
click the X button next to the OUT port name.
3. To remove the association between all the video router OUT ports and the player
channel, click the Clear All button.
