EVS Multicam – Version 10.04 – Configuration Manual
EVS Broadcast Equipment SA – January 2011
Issue 10.4.A
67
3.13 EVS CONTROLLER SETTINGS
EVS Controller p.6.1
[F1]Effect duration for Take: 00s05fr
[F2]Fast jog : 20x
[F3]PGM Speed/Var Max : 50%
[F4]Lever engage mode : Direct
[F5]Second lever range : -100% <-> +100%
[F6]Recall Clip Toggle : Enable
[Menu]Quit [Clr+F_]Dft [F9]PgUp [F0]PgDn
3.13.1 E
FFECT
D
URATION FOR
T
AKE
Possible range: 00s00fr to 20s00fr. Default: 00s05fr
This parameter defines the duration of the transition when using the TAKE key to
chain 2 sequences in PGM+PRV mode.
3.13.2 F
AST
J
OG
Possible values: 01 to 20 times. Default: 20x
This parameter sets the increment of the jump when in Fast Jog mode.
3.13.3 P
GM
S
PEED
/V
AR
M
AX
Possible values: 1 – 400%. Default: 50%
During playback, if PGM Spd or VarMax has been enabled in the secondary menu
of the Remote Panel, the lever range will be adapted so that:
• the only playback value for any position of the lever other than 0, is the one
specified by this parameter in the setup (PGM Spd mode ON)
OR
• the speed range defined by the lever is limited to the value specified by this
parameter (VarMax mode ON).
3.13.4 L
EVER
E
NGAGE
M
ODE
Possible values: Direct (default) / Current speed
The speed variation depends on the position of the T-Bar lever.
• Direct mode: the lever will engage directly when moved, resulting in a speed
jump to the desired speed determined by the lever arm position.
• Current speed mode: the lever will only engage when it reaches the current
playback speed, whereas a move of the lever arm in the opposite direction of
the current speed will result in a direct speed change.
