Issue
10.04.A
EVS Multicam – Version 10.04 – Configuration Manual
EVS Broadcast Equipment SA – January 2011
46
3.7 OSD SETTINGS
OSD Settings p.1.1
[F1]Genlock Error Msg: Yes
[F2]Disk Error Msg : Yes
[F3]Network Error Msg: Yes
[F4]Cue number on OSD: Yes
[F5]Keyword info : No
[Menu]Quit [Clr+F_]Dft [F9]PgUp [F0]PgDn
3.7.1 G
ENLOCK
E
RROR
M
SG
Possible values: Yes (default) / No
This function enables or disables the Genlock information on the output monitor. If
Genlock reference is not correct, the !GkV message appears on the output
monitor.
3.7.2 D
ISK
E
RROR
M
SG
Possible values: Yes (default) / No
This function displays an error message (!Raid) on the output monitor when a disk
is faulty.
Note
The server is equipped with a RAID disk array. This means that the
operation can continue seamlessly even with 1 faulty disk. If 1 disk is
disconnected during operation, the “!Raid” message appears on all
output monitors, and another message appears when the operator shuts
down the application, to invite him to replace the disk and rebuild the
RAID array.
Refer to the Technical Reference manual for details on the RAID system
and its maintenance.
3.7.3 N
ETWORK
E
RROR
M
SG
Possible values: Yes (default) / No
This function displays an error message (!Net) on the output monitor when the
network connection is faulty and another message (Net) when the network
becomes available again and the system is trying to re-connect.
