EVS Multicam – Version 10.04 – Configuration Manual

EVS Broadcast Equipment SA – January 2011

Issue 10.4.A

25

2.6.5 U

SE OF

GPI

S WITH

P

ROTOCOLS

L

IMITATIONS FOR

P

ROTOCOLS

•

For all protocols (excepted AVSP), use the channel assignment (PGM1-6), not

the device protocol type (Sony BVW75, Odetics).

•

AVSP does not require any GPI IN setting in the Setup menu because they are

defined through specific serial AVSP commands.

F

UNCTIONS

I

MPLEMENTED PER

P

ROTOCOL

•

AVSP:

Play, Stop, Still, Recue, GotoClipIN, GotoClipOUT, Next, Skip

•

Sony:

Play, Pause, Recue, Previous, Next, Skip

•

DD35:

Play, Pause, Recue, Previous, Next, Skip

•

Odetics:

Play, Pause, Recue, Next

•

VDCP:

Play, Pause, Recue, Previous, Next, Skip
