EVS MulticamLSM Version 10.04 - January 2011 Configuration Manual - Manual (Page 50)

Issue
10.04.A
EVS Multicam – Version 10.04 – Configuration Manual
EVS Broadcast Equipment SA – January 2011
42
3. Setup from the
Remote Panel
3.1 INTRODUCTION
When you work in LSM mode, the Setup menu available on the Remote Panel
allows you to define parameters. The values assigned to the parameters are saved
as soon as they are assigned.
Important
Prior to using Multicam, the operator should enter the Setup menu and
set all necessary parameters. If clips are stored with certain parameters
and the operator wishes to change them afterwards, those clips and
playlists will not change. It is thus important to set these parameters
first.
3.2 GENERAL LAYOUT
The following diagram shows the Remote Panel along with a brief description of
each area.
1. F-keys & small
buttons
Multi-purpose keys
2. Soft keys With LCD display, allows the operator to enter the
Multicam MENU system
3. Lever Initiates slow motion and playlist replay
4. Jog dial Used to accurately cue disk recorder
5. Operational
block 1
See Multicam Operational manual for more information
6. Operational
block 2
See Multicam Operational manual for more information
7. LCD Display Provides current status of system
Note
The operational buttons have PRIMARY and SECONDARY functions and
are divided into upper and lower sections. By pressing the SHIFT button
you gain access to the secondary functions.
