EVS Multicam – Version 10.04 – Configuration Manual
EVS Broadcast Equipment SA – January 2011
Issue 10.4.A
57
If no target is defined in these parameters, the user will be able to define the
requested target when (s)he calls the PUSH function.
3.9.11 M
ODE
Possible values: Short / Long
This parameter specifies how the clips should be sent using the PUSH function:
• Short: The clips are sent from the Short IN to the Short OUT points, to which
the guardbands of the destination machine are added.
• Long: The clips are sent from the Protect IN to the Protect OUT.
3.9.12 R
ECEIVE
P
AGE
Possible values: Select one or more clip pages from 1 to 10. Default: p.5
This parameter specifies the page of your machine where clips sent to you by
other network operators using the PUSH function must be stored.
How to Specify PUSH Receive Page(s)
To specify the page(s) to which the clips pushed from another network operator
will be stored, proceed as follows:
1. In the 2 n d page of Clip parameters, press the F5 key to edit the PUSH
Receive Page parameter.
2.
Press the F_ key corresponding to the page number you want to
select/unselect as PUSH Receive Page.
The selected pages will be highlighted on the LCD and the corresponding F_
keys light red. F_ keys of unselected pages light green.
3. Press ENTER to validate your selection.
