Issue
10.04.A XSense – Version 10.04 – Operating Manual
EVS Broadcast Equipment – January 2011
12
4. Remote Panel
Operations
4.1 OPERATIONS
4.1.1 RECORD
This key lights red when the system is recording. Pressing this key brings the
system in E/E (“live”) mode, and starts the record if necessary (depending on the
settings of the Setup menu). The E/E mode is actually playing pictures already
recorded by the system, and has a delay of 3 frames compared to the live source,
on all audio and video tracks.
4.1.2 MARK
This function marks up to 256 cues that can be marked while recording or playing.
The cues are marked on the LIVE or PLAYBACK program depending on the value
set in the Setup menu. When the operator has marked 256 cues, the next one will
overwrite the oldest one.
4.1.3 LAST CUE
This function re-cues the EVS server to previous cue point relative to the current
timecode position. Each time the Last Cue button is pressed, the EVS server re-
cues to the previous cue, etc. When recalling a cue point, the cue number appears
in the upper left corner of the OSD if this option is enabled in the Setup menu
(page 1.1, F4)
4.1.4 PLAY
This function initiates a forward motion. It can also be used to start playback of
playlists and clips (refer to PLST command).
When Pgm Spd is OFF, the default playback speed when pressing the PLAY key is
100% for standard pictures, 33% for Super Motion pictures with a Triple Speed
camera (SD), and 50% for Super Motion pictures with a Double Speed camera
(HD),.
When Pgm Spd is ON, the value defined in the Setup for this parameter is used.
Note
The Var Max option is not available with XSense.
