10.04.A XSense – Version 10.04 – Operating Manual
EVS Broadcast Equipment – January 2011
6
5. Operational
Block 2
PLAY Initiates playback
NETWORK Enters the XNet menu. (connect to other servers on the
network)
LAST CUE Re-cues EVS server to previous cue point
GOTO TC Allows timecode entry, with «F» keys
FAST JOG Used with jog dial for rapid, manual re-cue. This mode is
automatically reset after PLAY/LIVE commands.
MARK Used to enter re-usable cue point (256 cycling cues).
RECORD Initiates “E2E” mode
RETURN Inside a clip, allows the operator to return to the same
picture inside the record train, if it still exists.
PRV CTL Enables/disables the Preview Control mode.
PAGE Selects current clip page, from 1 to 10.
6. LCD Display Provides current status of system
2.2 LED COLORS
A selected key lights red.
When a key lights green, it means a value in relation with this key exists.
For example: F1 to F0 keys
• Green light means a clip has been stored in relation with the key.
• Green flashing light means a clip is being created.
• Red light means the clip associated to the key is playing or is ready to play.
• Red flashing light means a clip is being deleted (in network mode)
