When the IN point has been marked, the display switches to:
Cam A +2fields
Replace Int.Loop Ext.Loop
The Int. Loop (B) and Ext. Loop (C) keys are blinking.
5. If you want to specify the OUT point for the Replace section at this stage,
jog to the requested point and press the OUT key. Otherwise, you can define
the OUT point while you perform the Replace.
6. Press the B or C key to select whether you will use the internal loop or
external loop to perform the Replace.
For more information on the loop type and additional parameters, refer to
the section ‘Loop Mode in the Replace Function’, on page 134.
The playlist is cued before the IN point (to create guardbands), ready to be
initiated.
A message appears on Remote: “Start Replace: play button”.
7. Press the Play key on the Remote Panel to shift to the Replace Playback
mode and start the Replace process.
8. If you have not defined the OUT point for the Replace in step 5, press the
OUT key when you reach the desired OUT point.
While the Replace is being performed, the following messages are displayed
on the OSD:
“Replace in Progress”
“Clipping guardbands”
“Replace by clip xxx”
On the Remote Panel, a confirmation message pops up:
Replace in/out by clip xxx ?
MENU: Cancel – ENTER: OK.
9. Press Enter on the Remote Panel to validate the Replace:
The material between the IN and OUT points is replaced with the newly
created clip. The playlist returns to Playlist Edit mode, positioned at the end
of the inserted clip.
You can also cancel the Replace by pressing the Menu key on the Remote
Panel.
