10.04.A XSense – Version 10.04 – Operating Manual
EVS Broadcast Equipment – January 2011
134
11.17.6 L
OOP
M
ODE IN THE
R
EPLACE
F
UNCTION
L
OOP
T
YPE
When the IN point has been marked, the display switches to:
Cam A +2fields
Replace Int.Loop Ext.Loop
The Int. Loop and Ext. Loop keys are blinking.
Before entering the Replace Playback mode, the operator has to choose between
Internal Loop or External Loop.
The Internal Loop is the same loop as the existing loop process.
The External Loop allows you to select on which channel you will physically re-
record the output of your PGM. The link is physical: it is necessary to make the
video link manually with a router or video/audio cables, it is not done inside the
server.
A
DDITIONAL
L
OOP
P
ARAMETERS
Additional parameters are available for the external loop:
• With the Cam A function (SHIFT+C), you can select the camera the PGM will
be recorded to for the external LOOP process. Press SHIFT+C until the
desired camera is selected.
• With the +2 fields function (SHIFT+D), you can select by how much the video
coming back to your record channel will be delayed. If you are using a DVE, it
could introduce a delay. This system is based on the assumption that audio
and video are in sync when they hit the record channel. The delay value
cannot be negative.
Select SHIFT+D to highlight the delay value and the display allows you to add
frames or fields of delay to the delay value. Pressing either MENU or SHIFT+D
will leave this mode.
