screen of the Remote displays the complete list of available systems on the
network. The list is organized by the order of connection to the network. Up to 4
pages are available to display up to 31 servers.
The PREVIOUS and NEXT keys appear only when some machines are not visible
on the current page.
L
OCAL
M
ODE
The local system is identified with the Local sign after the name of the system.
The Local function (A) gives direct access to the Local mode and is highlighted
when Local mode is activated.
C
LIPS
M
ODE
The Clip function (B) allows the operator to connect to the clip banks of another
EVS server connected to the network. In other words, the VGA clip screen and the
F_ keys of the Remote show the clips from the selected EVS server. If the
operator presses the RECORD key, he goes in LIVE mode on the local record
trains.
R
ECORDS
M
ODE
When the operator selects one of the EVS servers in the network menu, he
connects the record trains to this EVS server. This means that the next time he
presses the Records function (C) the active channels will go in LIVE mode (or
near LIVE mode for remote trains
) on the record trains of the selected EVS
server. The clips remain connected to the EVS server they were connected to.
C
LIPS
+R
ECORDS
M
ODE
The Clip+Rec function (D) allows the operator to both connect to the clips banks
and to the record trains of a remote server. The VGA clip screen and the F_ keys
of the Remote Panel show the clips from the selected server. The next time the
operator presses the RECORD key, the active channels will go in LIVE mode (or
near LIVE mode for remote trains) on the record trains of the selected EVS server.
Select the function key corresponding to the remote system, then the LCD display
returns to the normal mode:
The names of the remote systems are now displayed after the Page and Bank
information and in the Title bar of the Clip screen.
PGM1 112B/04
*PRV1* CAM B
AUX
Clip
MIX
Sw to IN
PGMSpd
PREF
P.1 B.1 Clips: ALBERT Records: MICHEL
PL 11: <
Msg:
LOCAL
SYNC
PRV
CAM A
CAM B
CAM C
CAM D
