Prestige 1600 Universal Access Concentrator
DSL Port Setup
6-1
Chapter 6
DSL Port Setup
This chapter explains how to edit DSL Port information.
Use Menu 6 to configure the DSL ports. Select 6 from the Main Menu to enter Menu 6 - Slot Selection.
The Prestige automatically detects which network module is inserted in each slot. The following menu appears
when you have 2 ISDL network modules inserted in slots 1 and 2.
Note that ISDL network modules (32 ports per module) may only be inserted in slots 1 and 2 but not
slot 3. ADSL or SDSL network modules (24 ports per module) may be inserted in either slots 1, 2 or 3.
Combinations of network modules are also allowed.
Figure 6-1 Menu 14 - IDSL Port setup
Choose a slot to configure by entering its index number. The following screen displays an IDSL module in slot 1 of
a Secondary 3 device.
Menu 6 - Slot Selection
1. Slot 1 Configuration(IDSL NM)
2. Slot 2 Configuration(IDSL NM)
3. Slot 3 Configuration(N/A)
Please enter selection:
