Prestige 1600 Universal Access Concentrator
IP Policy Routing
16-3
Table 16-1 IP Routing Policy Summary
Abbreviation
Meaning
Criteria
SA
Source IP address
SP
Source port
DA
Destination IP address
DP
Destination port
P
IP layer 4 protocol number(TCP=6,UDP=17…)
T
Type Of Service of Incoming packet
PR
Precedence of incoming packet
Action
GW
Gateway IP address
T
Outgoing Type of Service
P
Outgoing Precedence
Type Of Service
NM
Normal
mD
Minimum Delay
MT
Maximum Throughput
MR
Maximum Reliability
MC
Minimum Cost
Enter a number from 1 to 6 to display Menu 25.1.1 - IP Routing Policy (see the next figure). This menu allows you
to configure a policy rule.
Figure 16-3 Menu 25.1.1 - IP Routing Policy
Menu 25.1.1 - IP Routing Policy
Policy Set Name= test
Active= Yes
Criteria:
IP Protocol = 6
Type of Service= Normal
Packet length= 40
Precedence = 0
Len Comp=
Source:
addr start= 1.1.1.1
end= 1.1.1.1
port start= 20
end= 20
Destination:
addr start= 2.2.2.2
end= 2.2.2.2
port start= 20
end= 20
Action= Matched
Gateway addr = 192.168.1.1
Log= No
Type of Service= Max Thruput
Precedence = 0
Press ENTER to Confirm or ESC to Cancel:
Press Space Bar to Toggle.
