Prestige 1600 Universal Access Concentrator
4-4 W AN Port Setup
4.3.2 DLCI
The carrier gives you a DLCI (Data Link Connection Identifier) for each frame relay connection to a destination.
Identifiers can range from 1 to 991 with restrictions as shown in the following table. The default DLCI for the first
connection is 16.
Table 4-3 Data Link Connection Identifiers
DLCI Usage
0 Channel Signaling
1-15 Reserved
16 - 991 Frame Relay
4.3.3 CIR (Committed Information Rate)
The carrier programs virtual circuits into the network between your sites and charges you for a specific level of
service called the committed information rate (CIR). The CIR is basically a guarantee that the carrier will always
have that bandwidth available. The CIR limit for the Prestige is 8Mbps. The sum of CIRs from all channels in a line
cannot exceed 8Mbps due to the processing limit of the P1600 CPU.
4.3.4 EIR (Excess Information Rate)
This is the burst capability of the connection, i.e., the maximum allowable data transfer rate. EIR must be greater
than or equal to the CIR.
4.3.5 How To Configure Frame Relay for Internet Access
Go to Menu 4 - Internet Access Setup, move the cursor to the Edit Frame Relay Options= field, press the
[SPACEBAR] once to display Yes and then press [ENTER]. This takes you to Menu 4.2 - Internet Setup Frame
Relay Options shown next.
Figure 4-5 Menu 4 - Internet Access Setup
Menu 4 - Internet Access Setup
ISP's Name= ChangeMe
My Login= 1234
My Password= ********
Network Address Translation= SUA Only
My WAN Addr= 0.0.0.0
Address Mapping Set= N/A
Edit Frame Relay Options= No
Press ENTER to Confirm or ESC to Cancel:
