Prestige 1600 Universal Access Concentrator
Getting to Know Your Prestige 1-1
Chapter 1
Getting to Know Your Concentrator
This chapter describes the key features, benefits and applications of your Prestige.
The Prestige 1600 is a scalable, high-performance, easy-to-configure access concentrator. It consolidates multiple
traffic streams onto a single backbone network. It can be deployed at either the customer’s premise (CP) or a
service provider’s Central Office (CO).
Equipped with one 10/100M Ethernet port, three network module (NM) slots, one WAN interface and one optional
five-port 10M/100M LAN switch card, the architecture of the Prestige 1600 allows network modules of different
generations to coexist in the same chassis and to inter-operate with the same system module.
With its flexible and scalable architecture, you can start with a single P1600 chassis to address low or medium
density network requirements and expand with up to four additional P1600s. With the optional five-port 10/100M
Ethernet switch installed, you can connect up to five units.
1.1 Overview of the Prestige 1600
Physical Dimensions
! Chassis: 17.3" (W) x 13.39" (L) x 2.6" (H); 44cm (W) x 34cm (L) x 6.6cm (H)
! DSL network module: 5.3" (W) x 12.2" (L) x 0.94" (H); 13.5cm (W) x 31cm (L) x 2.4cm (H)
! Rack-mounting options: EIA 19" or 23" front or mid-mount central-office style
Power Requirement
! Built-in 100V-240VAC, 50-60 Hz switching power supply
Operating Environment
! Temperature: 0ºC - 50º C
! Humidity : 20 - 95%
IDSL Interface
! Two 16-port IDSL network modules.
! Up to 160 IDSL ports. 32 IDSL ports in each P1600 chassis.
! IDSL Server only
ADSL Interface
! Three 8-port ADSL network modules.
!
Up to 120 ADSL ports (112 if using the 5-port Ethernet switch card). 24 ADSL ports in each P1600
chassis.
SDSL Interface
!
Three 8-port SDSL network modules.
!
Up to 120 SDSL ports (112 if using the 5-port Ethernet switch card). 24 SDSL ports in each P1600 chassis.
