Prestige 1600 Universal Access Concentrator
System Information and Maintenance 14-4
(*) indicates the port you can reset (press “b”) or drop (press “d”) the counters. Press “i” to move the asterisk to the
preceding port and “j” to the next port. Press “a” to reset all ports. Press [ESC] to exit this menu.
Figure 14-5 Menu 24.1.2 - NM-1 Status
Table 14-3 NM Status Fields
Field Description
Port The DSL Port number.
TXPkts The number of transmitted packets on this port.
RXPkts The number of received packets on this port.
Err(or)s The number of error packets on this port.
Tx (Byte / s) The number of bytes transmitted in the last second.
Rx (Byte / s) The number of bytes received in the last second.
Up Time Elapsed time this port has been up.
14.1.3 Route Status
Enter 3 in menu 24.1 to bring up the following screen showing detailed information on the status of the router.
Figure 14-6 Menu 24.1.5 - Router Status
Field Description
Dest This is the destination IP address.
FF This is for ZyXEL internal debugging.
Menu 24.1.2 - System Maintenance(IDSL NM 1)
Port Link Speed TXPkts RXPkts Errs TX(Byte/s) RX(Byte/s) Up Time
*1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16 Up
Up
Up
Up
Up
Up
Up
Up
Up
Up
Up
Up
Up
Up
Up
Up 128K
128K
128K
128K
128K
128K
128K
128K
128K
128K
128K
128K
128K
128K
128K
128K 81899
12070
82431
63184
35762
40203
81448
81504
81361
81724
81756
81707
81875
81869
81862
81822 78655
12046
78907
60558
34822
38293
78414
78455
78374
78567
78603
78606
78656
78656
78656
78655 0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0 12
125
0
0
0
0
0
0
0
0
0
0
0
0
0
0 0
160
0
0
0
0
0
0
0
0
0
12
0
0
0
0 11:55:05
11:53:39
11:53:46
11:45:41
11:40:48
11:26:53
10:38:57
10:38:58
14:00:00
14:15:24
18:07:17
10:00:00
16:25:32
16:25:32
16:25:52
16:25:52
Press Command:
COMMANDS: a-Reset All b-Reset d-Drop i-up j-down ESC-Exit
Dest FF Len Device Gateway Metric stat Timer Use
192.168.1.0 00 24 enet0 192.168.1.1 1 041b 0 0
default 01 0 Idle Scone 2 002b 0 0
Press Enter to Exit:
