Prestige 1600 Universal Access Concentrator
Internet Access 5-1
Chapter 5
Internet Access
This chapter shows you how to configure the Prestige 1600 primary and Prestige 1600 standalone for
Internet access.
5.1 Introduction
Menu 4 - Internet Access Setup of the SMT allows you to configure the Internet access parameters in a single
screen. For Internet access using the Prestige 1600 standalone you need to only set up a default route using Menu
12 - Static Default Route. While configuring your Prestige for Internet access you have to be careful when setting
the IP addresses to avoid IP conflict. The following section shows the various IP networks in the P1600.
5.1.1 IP Address assignment
Table 5-1 Default DSL IP Address Assignment
Configuration
Type (Menu 1)
P1600 IP
address
Port numbers IP address range assigned to
DSL Clients (Menu 6.1)
IDSL:16 ports 192.168.255.1 ~ 192.168.255.16 Slot
1
ADSL/SDSL:
8 ports 192.268.255.1 ~ 192.168.255.8
IDSL:16 ports 192.168.255.17 ~ 192.168.255.32 Slot
2
ADSL/SDSL:
8 ports
192.168.255.17 ~ 192.168.255.24
IDSL Not Available
Primary 192.168.1.1
Slot
3
ADSL/SDSL:
8 ports
192.168.255.33 ~ 192.168.255.40
IDSL:16 ports 192.168.254.1 ~ 192.168.254.16 Slot
1
ADSL/SDSL:
8 ports 192.268.254.1 ~ 192.168.254.8
IDSL:16 ports 192.168.254.17 ~ 192.168.254.32 Slot
2
ADSL/SDSL:
8 ports
192.168.254.17 ~ 192.168.254.24
IDSL Not Available
Secondary 1 192.168.1.2
Slot
3
ADSL/SDSL:
8 ports
192.168.254.33 ~ 192.168.254.40
IDSL:16 ports 192.168.253.1 ~ 192.168.253.16 Secondary 2 192.168.1.3 Slot
1
ADSL/SDSL:
8 ports 192.268.253.1 ~ 192.168.253.8
