Prestige 128MH PSTN Router/Hub
5-2 Chapter 5 Remote Node Configuration for LAN-to-LAN
Figure 5-1. Menu 11 - Remote Node Setup
Step 3. When Submenu 11.1. - Remote Node Profile appears, select the connection type
depending on your particular application (dial-up line or leased line application). Move
the cursor to the Connection Type field and use the space bar to toggle (Switch/Leased).
Set the Connection Type to one of the following values:
l [Switch]: for Dial-up Line Application, as shown in Figure 5-2.
l [Leased]: for Leased Line Application. Selecting [Leased] will bring you to the
Submenu 11.1.2 - Remote Node Profile for leased line application.
Figure 5-2. Menu 11.1 - Remote Node Profile for Dial-up Line Applications
Menu 11.1 - Remote Node Profile
Rem Node Name= ?
Active= Yes
Connection Type= Switch
Call Direction= Both
Incoming:
Rem Login= ?
Rem Password= ?
Rem CLID=
Call Back= No
Outgoing:
My Login= ?
My Password= ?
Authen= CHAP/PAP
Pri Phone #= ?
Sec Phone #=
Device Type= 56K Modem
Route= IP
Bridge= No
Edit PPP Options= No
Rem IP Addr= ?
Edit IP/IPX/Bridge= No
Edit Script Options= No
Telco Option:
Allocated Budget(min)= 0
Period(hr)= 0
Session Options:
Input Filter Sets=
Output Filter Sets=
Call Filter Sets=
Idle Timeout(sec)= 300
Press ENTER to CONFIRM or ESC to CANCEL:
Press Space Bar to Toggle.
IP Address
Assigned by ISP
Menu 11 - Remote Node Setup
1. ________
2. ________
3. ________
4. ________
Enter Node # to Edit:
