Prestige 128MH PSTN Router/Hub
13-2 Chapter 13 System Maintenance
13.1 System Status
System Status is a tool that can be used to monitor your Prestige. Specifically, it will give you
information on the status of your system software version, WAN Port, number of packets sent and
number of packets received, as shown in Figure 13-2.
Figure 13-2. Menu 24.1 - System Maintenance - Status
Follow the procedure below to go to the System Status Menu.
Step 1. Select option 24 from the Main Menu to access Menu 24 - System Maintenance.
Step 2. From Menu 24, select option [1. System Status].
Step 3. There are five possible commands in Menu 24.1 - System Maintenance - Status.
l Entering 1 or 2 or 3 will disconnect the call on the specified WAN port;
l Entering 8 will disconnect the calls on all WAN ports,
l Entering 9 will reset the counters; and [Esc] will exit this screen.
Menu 24.1 -- System Maintenance - Status
Port
1
2
3
Status
Idle
Down
Down Kbps
0Kbps
0Kbps
0Kbps TXPkts
0
0
0
RXPkts
0
0
0
Errors
0
0
0
Up Time
0:00:00
0:00:00
0:00:00
Total Outcall Time: 0:00:00
Ethernet:
Status: 10M/Full Duplex
TX Pkts: 26
RX Pkts: 0
Collisions: 0
Name: p128MH
RAS S/W Version: V1.6(e01) | 2/6/98
Ethernet Address: 00:a0:c5:01:23:45
LAN Packet Which Triggered Last Call:
Press Command:
CMDS: 1-Drop Port1 2-Drop Port2 3-Drop Port3 8-Drop All 9-Rst Cnt ESC-Exit
