Prestige 128MH PSTN Router/Hub

13-4

Chapter 13 System Maintenance

Table 13-1.

System Maintenance - Status Menu Fields (continued)

Field

Description

14. Name

Displays the system name of your Prestige. This information can be modified in
Menu 1 - General Setup.

15. RAS S/W

Version

Refers to the version of the current RAS software.

16. Ethernet

Address

Refers to the Ethernet MAC address assigned to your Prestige.

17. LAN Packet

Which Triggered
Last Call

Shows the first 48 octets of the LAN packet that triggered the last outgoing call.
There are three different types of packets: IP, IPX, and RAW. By viewing the
packet information, you can determine which station has sent a packet to cause
your Prestige to make an outgoing call.

Figure 13-3 shows two examples of LAN Packets: the first of an ICMP Ping packet (Type: IP)
triggering the call and the second with a SAP broadcast packet (Type: Raw) triggering the call.

With this information, you can determine the source IP address of the packet or the source MAC
address of the packet.

Figure 13-3.

LAN Packet Which Triggered Last Call

LAN Packet Which Triggered Last Call: (Type IP)

45 00 00 3C 02 12 00 00 3B 01 36 49 00 00 00 00 C0 44 87 22 08 00 62 2B 20 04 00 00
00 08 A9 D0 C0 44 87 22 00 01 02 03 04 05 06 07 08 09 0A 0B

LAN Packet Which Triggered Last Call: (Type Raw)

FF FF 00 22 00 11 00 00 00 00 FF FF FF FF FF FF 04 52 00 00 00 00 00 40 95 90 04 B9
40 08 00 03 02 78 01 A5 A5 A5 A5 A5 A5 A5 A5

Source IP Address

Source MAC Address
