Prestige 128MH PSTN Router/Hub
6-2 Chapter 6 TCP/IP Configuration for LAN-to-LAN
6.1.1 Remote Node Setup
Follow the procedure in Chapter 5 - Remote Node Configuration for LAN-to-LAN to fill the
protocol-independent parameters in Menu 11 - Remote Node Profile. For the protocol-dependent
parameters, follow the instructions below. If you are configuring your Prestige to receive an
incoming call, you also need to set the default dial-in parameters in Menu 13.
To edit Menu 11.3 - Remote Node Network Layer Options shown in Figure 6-2, follow these
steps:
Step 1. In Menu 11.1, make sure [IP] is among the protocols in the Route field. (The Route
field should display Route = IP or Route = IP + IPX.)
Step 2. Move the cursor to the [Edit IP/IPX/Bridge] field, then press the space bar to toggle and
set the value to [Yes], and press [Enter]
to edit Menu 11.3 - Network Layer Options.
Figure 6-2. Menu 11.3- Remote Node Network Layer Options for a TCP/IP Application
Menu 11.3 - Remote Node Network Layer Options
IP Options:
Rem IP Addr: 0.0.0.0
Rem Subnet Mask= 0.0.0.0
My WAN Addr= 0.0.0.0
Single User Account= No
Server IP Addr= N/A
Metric= 2
Private= No
RIP Direction= Both
Version= RIP-2B
IPX Options:
Dial-On-Query= N/A
Rem LAN Net #= N/A
My WAN Net #= N/A
Hop Count= N/A
Tick Count= N/A
W/D Spoofing(min)= N/A
SAP/RIP Timeout(min)= N/A
Bridge Options:
Dial-On-Broadcast= N/A
Ethernet Addr Timeout(min)= N/A
Enter here to CONFIRM or ESC to CANCEL:
