Prestige 128MH PSTN Router/Hub
13-3 Chapter 13 System Maintenance
The following Table 13-1 describes the fields present in Menu 24.1 - System Maintenance -
Status.
It should be noted that items 1-17 in this Table 13-1 are READ-ONLY and are meant to be used
for diagnostic purposes.
Table 13-1. System Maintenance - Status Menu Fields
Field Description
1. Port Shows statistics for all WAN port respectively. These are the information displayed
for each port from items 6 to 11 in this table.
2. Status Shows the Remote Node the port is currently connected to or the status of the port
([Idle], [Calling], or [Answering]).
3. Kbps The current connecting speed.
4. TXPkts The number of transmitted packets on this port.
5. RXPkts The number of received packets on this port.
6. Error The number of error packets on this port.
7. Up Time Time this port has been connected to the current Remote Node.
8. Total Outgoing
call Time
Shows the total outgoing call time for all WAN ports since the system has been
powered up.
9. Ethernet Shows the current status of the LAN connection on your Prestige
10. Status Shows the current status of the LAN
11. TX Pkts The number of transmitted packets to LAN.
12. RX Pkts The number of received packets from LAN
13. Collision Number of collisions.
