Prestige 128MH PSTN Router/Hub
9-7 Chapter 9 Filter Configuration
9.2 Configuring a Filter Rule
There are four types of filter rules that you can configure. Some of the parameters will differ
depending on the type of rule. When you first enter the Filter Rule Menu, you will be presented
with Menu 21.1.1 - TCP/IP Filter Rule. If you wish to configure another type of filter rule, you
need to select the appropriate type (by pressing [Space bar]) under the Filter Type field and press
[Enter]. This will bring you to the corresponding menu.
9.2.1 TCP/IP Filter Rule
This section will show you how to configure a TCP/IP filter rule for your Prestige.
Figure 9-4 displays Menu 21.1.1 TCP/IP Filter Rule.
Figure 9-4. Menu 21.1.1 - TCP/IP Filter Rule
Menu 21.1.1 - TCP/IP Filter Rule
Filter #: 1,1
Filter Type= TCP/IP Filter Rule
Active= No
IP Protocol= 0 IP Source Route= No
Destination: IP Addr=
IP Mask=
Port #= 0
Port # Comp= None
Source: IP Addr=
IP Mask=
Port #= 0
Port # Comp= None
TCP Estab= N/A
More= No Log= None
Action Matched= Check Next Rule
Action Not Matched= Check Next Rule
Press ENTER to Confirm or ESC to Cancel:
Press Space Bar to Toggle.
