Prestige 128MH PSTN Router/Hub
2-18 Chapter 2 Hardware Installation & Initial Setup
2.8.2 Advanced WAN Port Setup
The Advanced WAN Port Setup Menu allows you to configure the AT Commands for the external
modem/ISDN TA connected to WAN port 1 and for the built-in 56K modems internally connected
to WAN port 2 and 3. Also, this menu lets you configure the call control parameters. For all of
Prestige 128MH WAN ports, follow the common Advanced WAN Port Setup procedure outlined
in this section.
Step 1. In Menu 2.1, move the cursor to the Advanced Setup field and press the space bar to
select [Yes], then press [Enter].
Step 2. When Menu 2.1.1 appears, fill in the appropriate AT commands and call control
parameters for the external modem or ISDN TA connected to the WAN port 1 and for
the internal modems on WAN port 2 and 3, as shown in Figure 2-10.
Figure 2-10. Menu 2.1.1 - Advanced WAN Port Setup
Menu 2.1.1 - Advanced WAN Port Setup
AT Command Strings:
Dial= atd
Drop= ~+++~ath
Answer= ata
Drop DTR When Hang Up= Yes
AT Response String:
CLID= NMBR
Called Id= TO
Speed= CONNECT
Call Control
Dial Timeout(sec)= 60
Retry Counter= 0
Retry Interval(sec)= N/A
Drop Timeout(sec)= 20
Call Back Delay(sec)= 15
Enter here to CONFIRM or ESC to CANCEL:
